10L Rotary Evaporator

The 10L rotary vacuum evaporator has a dual coil condenser for better condensation. It is available in an explosion-proof version.


  Features


- Teflon(PTFE) and fluorine rubber double rotating seal, patent technology to ensure high vacuum
- The temperature control system, accurate and reliable.
- In does not affect the system and solution under the condition of vacuum distillation. continuous collection
- The PTFE disscharge valve, corrosion resistance, no pollution.
- Adopt corrosion and high temperature resistance borosilicate glass.
- Rubber parts adopt new standard materials, easy to change for users.
- We have two kinds of conventional and explosion-proof type, can be selected according to the experimental environment.



  Detail


Rotating bottle - R-1010 Rotary Evaporator
- Rotary Bottle:
Large sise,easy to clean.With special handle, convenient disassembly.
- Brushless DC Motor:
Small size, light weight, large torque.Stable and reliable, simple repair and maintenance.Shock resistance, low noise, low vibration, smooth operation and long life.
Brushless DC Motor
Double coil condenser
- Double coil condenser:
All glass is GG-11 without bubble type, high definition. Double-layer coil, large evaporation area, good condensation effect.
- Clip:
All flanges are clamped and patented. For demolition, good sealing and high temperature resistance.
PTFE Clip

R-1010 Rotary Evaporator Detail



  For the perfect use of the entire rotary evaporator system you may need the following equipment


- Low temperature constant temperature reaction bath
- Circulating cooler
- Constant temperature circulator



  After sale


- 1 year warranty service and all life maintenance.
- Technical Egineer are avalible for oversea trainning.
- Free change for some parts
- Remote control technical consult
- Free installation DVD
- Maintenance plan



  Package


Package



  Transport


Logistics transportation

Model R-1010 Rortayr Evaporator
Optimum ambient temperature(℃) 5-35
Working power supply(V/Hz) Single phase 220/60
Main engine speed(RPM) 20-130
Main engine speed control Digital direct current stepless speed regulation
Rotary electric machine(W) Brushless 250
Temperature control(℃) Digital display temperature control,room temperature -99℃
Maximum vacuum(Pa) 399.9(Below 3mmHg)
Rotating bottle(L) 10
Recoverty bottle(L) 5
Condenser tube The vertical main cold+cold side,high efficiency reflux condenser.
Evaporation capacity(L/h) The water is more than 3.2 Alcohol is more than 6.5
Water bath pot material Stainless steel
Water bath pot size(mm) φ350*220
Lifting function Electric lift
Lift stroke(mm) 0-160
Whole power(Kw) 3.0
Outline dimension(mm) 920*550*1700


1. How many degrees does the cryogenic pump of the R-1010 cool down?

We can produce cryogenic pumps up to -120 ° C, and the DLSB series of cryogenic coolant circulation pumps range from -5 ° C to -120 ° C. With a 5L to 100L effluent capacity, you can choose from it. Customized requirements.


2. Does the circulating water vacuum pump have 110V/60Hz power?

Of course, the vertical circulating water vacuum pump has vacuum pump equipment of different powers such as 220V/50Hz, 220V/50Hz, 110V/60Hz. The SHZ series of circulating water vacuum pumps are suitable for rotary evaporators of 10L, 20L and 50L.


3. How to package glass equipment?

We package these glass equipment in a good non-fumigation standard plywood box, which can reduce the shock and better protect the glass part of the equipment.
